MACS
XLP
CAPACITY
25 – 75 kg/h
The maximum processing capacity of the MACS XLP is 75 kg per cycle (approximately 1 hour).
VOLUMINA
Volume of Feed Hopper: 125 L
Volume of Autoclave: 100 L
Process Capacity per Cycle: 250 L
TECHNICAL DATA
Dimensions (L x W x H): 1,57 m x 2,12 m x 2,09 m
Weight: 2 T
ENVIRONMENTAL IMPACT / ECO – BALANCE
Volume Reduction Potential per Year: 65.700 L
CO₂ Reduction Potential per 600 km: 2.795 T
MACS
135
CAPACITY
27 – 81 kg/h
The maximum processing capacity of the MACS 135 is 75 kg per cycle (approximately 1 hour).
VOLUMINA
Volume of Feed Hopper: 135 L
Volume of Autoclave: 85 L
Process Capacity per Cycle: 270 L
TECHNICAL DATA
Dimensions (LxWxH): 1,4 m x 2,2 m x 2,3 m
Weight: 2 T
ENVIRONMENTAL IMPACT / ECO – BALANCE
Volume reduction potential per Year: 70.956 L
CO₂ reduction potential per 600 km: 2.980 T
MACS
300
CAPACITY
30 – 90 kg/h
The maximum processing capacity of the MACS 300 is 90 kg per cycle (approximately 1 hour).
VOLUMINA
Volume of Feed Hopper: 350 L
Volume of Autoclave: 245 L
Process Capacity per Cycle: 300 L
TECHNICAL DATA
Dimensions (LxWxH): 1,85 m x 2,8 m x 2,85 m
Weight: 4,4 T
ENVIRONMENTAL IMPACT / ECO – BALANCE
Volume reduction potential per year: 178.704 L
CO₂ reduction potential per 600km: 7.506 T
MACS
500
CAPACITY
50 – 150 kg/h
The maximum processing capacity of the MACS 500 is 150 kg per cycle (approximately 1 hour).
VOLUMINA
Volume of Feed Hopper: 500 L
Volume of Autoclave: 245 L
Process Capacity per Cycle: 500 L
TECHNICAL DATA
Dimensions (LxWxH): 1,85 m x 2,8 m x 3,37 m
Weight: 4,6 T
ENVIRONMENTAL IMPACT / ECO – BALANCE
Volume reduction potential per year: 262.800 L
CO₂ reduction potential per 600km: 11.038 T
MACS
700
CAPACITY
70 – 210 kg/h
The maximum processing capacity of the MACS 700 is 210 kg per cycle (approximately 1 hour).
VOLUMINA
Volume of Feed Hopper: 350 L
Volume of Autoclave: 245 L
Process Capacity per Cycle: 700 L
TECHNICAL DATA
Dimensions (LxWxH): 2,85 m x 1,85 m x 2,8 m
Weight: 4,9 T
ENVIRONMENTAL IMPACT / ECO – BALANCE
Volume reduction potential per year: 367.920 L
CO₂ reduction potential per 600km: 15.453 T
MACS
800
CAPACITY
80 – 240 kg/h
The maximum processing capacity of the MACS 800 is 240 kg per cycle (approximately 1 hour).
VOLUMINA
Volume of Feed Hopper: 400 L
Volume of Autoclave: 260 L
Process Capacity per Cycle: 800 L
TECHNICAL DATA
Dimensions (LxWxH): 1,95 m x 2,7 m x 2,95 m
Weight: 5,5 T
ENVIRONMENTAL IMPACT / ECO – BALANCE
Volume reduction potential per year: 420.480 L
CO₂ reduction potential per 600km: 17.660 T
Underlying assumptions:
1 Capacity per cycle
2 Based on an average density of 0.1-0.3 kg/l
3 Based on 250 days of operation
4 Based on the MACS liquid program
5 kg CO₂-eq calculated using European data and consumption for a distance of approximately 600 km, truck (EURO5, 16-32 t), load weight of 9,210 kg (61.4 m³ volume x density 150 kg/m³)
